Earthing Design Services for HV & LV Electrical Installations

Alcomet offers professional Earthing Design Services for HV and LV electrical installations across the UK. Our experienced engineers deliver compliant, cost-effective earthing system designs supported by detailed soil resistivity surveys, advanced modelling and industry-leading analysis software.

HV/LV Earthing

• Designs that comply with all relevant standards – national and international standards including; BS EN 50522 , ENA 41-24, S34, BS 7430, BS7671, IEEE80
• Fully Designed systems using latest CDEGS software that provides a safe and cost effective solution. Taking into account touch and step potential safety calculations.
• Manufacturing experience and expertise utilising our knowledge of the products available to provide a tailored design that can be installed using the most appropriate and certified products

Soil resistivity Surveys (Wenner Method)

• A comprehensive soil resistivity survey is essential to creating an effective and safe earthing system. Inadequate and erroneous soil resistivity readings are likely to result in a flawed design.
• Our soil resistivity surveys take multiple readings at various depths across the site, the data is then modelled in CDEGS software to help produce a compliant design. The experience of our engineers is critical in ensuring the correct measurement and implementation of the test data

Analysis & Earthing Design Services

• Using the latest CAD and earthing simulation software (CDEGS) we can produce detailed earthing designs and drawings to include both HV/LV combined systems in compliance with the relevant project specifications & standards.
• EPR & Touch step safety calculations
